PD866EZ Multi-User Smart Meters

Application Scenarios:

Measurement & power meter box in commercial or public buildings,schools,apartment,residential buildings

PRODUCT OVERVIEW

The terminal integrates up to 42-way single-phase(or 14-way three phase) power  measurement display,prepayment control,energy metering and communication management.It has the characteristics of centralized installation,household metering,prepayment management,one-household-one-meter circular display,anti-theft and malignant load identification.Widely used in energy metering cost control and building energy efficiency management of smart buildings.It is more suitable for metering fee control and energy-saving management upgrading of construction property(commercial) management.The product has a variety of communication interfaces and network connection methods,which can be easily connected to the intelligent building metering energy efficiency management system.

KEY FEATURES

  •  Beautfiful appearance,exquisite volume
  •  Modular shape structure design
  •  simple operation and convenient maintenance for users
  •  External one-to-many card query and display terminal
  •  With RS485,WIFI,TCP/IP communication methods
  •  Swipe card self-service recharge and network remote fee control
  •  Mobile online experience
  •  All and more functions customizable



PARAMETER

PERFORMANCE DATA



Input











Nominal Value

Current:1.5(6)A, 5(20)A, 10(40)A, 15(60)A, 10(80)A, 20(80)A;

Voltage: 220V AC

Over Load

Continous: 1.2times,instantanneous voltage: 2times/1second(voltage)

Impedance

Current Side: ≤0.1Ω

Voltage Cnsumption

<1VA(each phase)

Frequency

45~65Hz

Accuracy

Direct: active 1, reactive 2;

Via Transformer: active:0.5S, reactive 2

Pulse Constant

Direct: 300imp/kWh

Via transformer: 6400imp/kWh

Displasy Range

0~99999999

Power Supply

Voltage Range

AC/DC 85~260V

Power Consumption

<5VA

Isolation

≥100MΩ

Frequency withstand Voltage

2KV/1min(AC: effecive value)

MTTF

≥50000h

Environment

Temperature

Working: -10~+50℃

Storage: -25~+70℃

Humidity

≤90%RH, no condensation, no corrosive gas site

Elevation

≤2000m





PD866EZ Multi-User Smart Meters
